FST6030SI
Volsun
Self-fusing Silicone Tape is a convenient, ready to use tape which can be used to make airtight and waterproof seals on many types of materials and applications including electrical connections, hoses, and cables and to reduce vibration of hand tools. It is tear, abrasion, and UV resistant and it withstands exposure to fuel, water, oil, acids, and many solvents. It is a class H Insulator. This product is designed to seal hoses and leaky plumbing, insulate electrical connections, wrap hand tool handles.
What are advantages of silicone self-fusing tape?
Standard colors: red, yellow, green, black (other colors can be customized)
Operating Temperature: -60℃~+180℃
The surface of the tape is not sticky to the touch, after peeling off, no sticky residue will be left
Strong self-adhesiveness can be produced in a short time, and it can be self-integrated after winding, which can be sealed and waterproof
The product can be wound into any shape, suitable for wrapping various electrical cable joints and intermediate joints
Anti-fouling, anti-corrosion, anti-ultraviolet, waterproof, ozone-resistant, anti-aging, suitable for various environments, suitable for outdoor operations
Item | Typical Data | Test Standard |
Tensile Strength | ≥3.5MPa | GB/T 528-2009 |
Elongation at break | ≥200% | GB/T 528-2009 |
Self-adhesive | ＞3.5N/cm | ASTM D2148 |
Flame Retardancy | V-0 | UL94 |
Dielectric strength | ≥22kV/mm | GB/T1408.1-2006 |
Volume resistivity | ≥1.3×1014Ω·m | GB/T1410-2006 |
Dimensions (Other sizes also can be customized)
Size | Width（mm） | Thickness（mm） | Package（M/Roll） |
20*0.8 | 20±2.0 | 0.8±0.08 | customized |
25*0.5 | 25±2.0 | 0.5±0.08 | customized |
25*0.8 | 25±2.0 | 0.8±0.08 | customized |
25*1.0 | 25*1.0 | 1.0±0.08 | customized |
30*1.5 | 30±2.0 | 1.5±0.08 | customized |
50*0.5 | 50±2.0 | 0.5±0.08 | customized |
How to use silicone self-fusing tape?
Wipe the surface of the object to be protected, tear off the isolation film, and wrap half of the
self-adhesive tape on the object to be protected
Finish installation
Before installation, the surface of the object to be protected must be cleaned, free from dirt and debris, so as not to affect the installation and use
When tearing off the film and attaching it to the protected object, a small amount of tearing off the film is required. Too much film tearing at one time will cause wrinkles and stick to impurities during use, which will affect the use
When pasting, one-half overlap is required to ensure the protective effect of the product
The environment should be kept as clean as possible during use to prevent impurities from sticking to the tape and affecting the adhesive force
