Suzhou Volsun Electronics Technology Co., Ltd.
Volsun arc-resistant fireproof tape is specially designed for safety protection in power systems. It has excellent arc-resistant performance and excellent fire-retardant properties. Under high temperature or arc fault conditions, it can effectively isolate the arc, prevent the spread of fire, and ensure the safe operation of lines and equipment. At the same time, it has good electrical insulation performance, high voltage resistance, anti-aging and wear resistance, and is suitable for various harsh environments.
| Quantity: | |
|---|---|
FST8077
VOLSUN
FST8077 Arc-resistant flame-retardant tape (flame-retardant tape for cable) is a special tape with two-way fire resistance, heat insulation and arc resistance characteristics. The flame retardant oxygen index is much higher than similar international products. The quality is excellent and the industry leader is widely used. In the fields of power, communications, fire protection, etc., it can be used for the protection of the entire cable, and it can also be used for key protection of weak parts such as joints. Controlling the fire hazard locally can greatly reduce the loss, which is unmatched by the traditional fire blocking concept.
Standard color：Black
Fire protection of high and low voltage cables in cable tunnels and substations
Fire and explosion protection of cable middle joint
Fire protection of cables in communication equipment room
Fire protection of fire pipes and cables
Item | Typical value | Test method |
L\w temperature tensile (-15℃±2℃) | ≥60% | XF 478-2004 |
self-adhesive | No loose phenomenon | XF 478-2004 |
Water resistance (soak for 15 days) | No blistering, wrinkling, delamination, cracking and other phenomena | XF 478-2004 |
Acid, alkali and salt resistance (soaking for 7 days) | No blistering, wrinkling, delamination, cracking and other phenomena | XF 478-2004 |
Oxygen index | ≥45 | GB/T2406-2008 |
Flame retardant (carbonization height) | ≤2.0 | XF 478-2004 |
Prethermal aging | ||
Tensile strength | ≥3.0MPa | XF 478-2004 |
Elongation at break | ≥500% | XF 478-2004 |
After thermal aging (100℃±2℃) *168h | ||
Maximum rate of change of tensile strength | ±20% | XF 478-2004 |
Maximum rate of change of elongation at break | ±20% | XF 478-2004 |
Type | W(mm) | D(mm) | L(m) |
FST8077-60 | 60±1.5 | 0.70±0.1 | 5 |
Clean the surface of the protective cable, open the package, and check whether the product is in good condition
Secure the end of the tape and make half lap wrap
It can be wound twice according to the protection requirements
The installation is complete
Clean the surface of the cable before installation to avoid adverse effects on the service performance
The winding installation requires half lap, to ensure that the product protection effect is the best
When using a new roll of adhesive tape, wrap it with the wrapped tape by 10-15cm lap to ensure the adhesive force of the products and prevent delamination and falling off
FST8077 Arc-resistant flame-retardant tape (flame-retardant tape for cable) is a special tape with two-way fire resistance, heat insulation and arc resistance characteristics. The flame retardant oxygen index is much higher than similar international products. The quality is excellent and the industry leader is widely used. In the fields of power, communications, fire protection, etc., it can be used for the protection of the entire cable, and it can also be used for key protection of weak parts such as joints. Controlling the fire hazard locally can greatly reduce the loss, which is unmatched by the traditional fire blocking concept.
Standard color：Black
Fire protection of high and low voltage cables in cable tunnels and substations
Fire and explosion protection of cable middle joint
Fire protection of cables in communication equipment room
Fire protection of fire pipes and cables
Item | Typical value | Test method |
L\w temperature tensile (-15℃±2℃) | ≥60% | XF 478-2004 |
self-adhesive | No loose phenomenon | XF 478-2004 |
Water resistance (soak for 15 days) | No blistering, wrinkling, delamination, cracking and other phenomena | XF 478-2004 |
Acid, alkali and salt resistance (soaking for 7 days) | No blistering, wrinkling, delamination, cracking and other phenomena | XF 478-2004 |
Oxygen index | ≥45 | GB/T2406-2008 |
Flame retardant (carbonization height) | ≤2.0 | XF 478-2004 |
Prethermal aging | ||
Tensile strength | ≥3.0MPa | XF 478-2004 |
Elongation at break | ≥500% | XF 478-2004 |
After thermal aging (100℃±2℃) *168h | ||
Maximum rate of change of tensile strength | ±20% | XF 478-2004 |
Maximum rate of change of elongation at break | ±20% | XF 478-2004 |
Type | W(mm) | D(mm) | L(m) |
FST8077-60 | 60±1.5 | 0.70±0.1 | 5 |
Clean the surface of the protective cable, open the package, and check whether the product is in good condition
Secure the end of the tape and make half lap wrap
It can be wound twice according to the protection requirements
The installation is complete
Clean the surface of the cable before installation to avoid adverse effects on the service performance
The winding installation requires half lap, to ensure that the product protection effect is the best
When using a new roll of adhesive tape, wrap it with the wrapped tape by 10-15cm lap to ensure the adhesive force of the products and prevent delamination and falling off
