Suzhou Volsun Electronics Technology Co., Ltd.
| Quantity: | |
|---|---|
VS-RILIC
Volsun
The Cold Shrink Tube for Offshore Photovoltaic MC4 Connectors is designed to protect your connectors in harsh offshore environments. Made from high-quality silicone rubber, it offers exceptional weather resistance, ozone aging resistance, and UV protection. This tube is ideal for low voltage applications and provides reliable sealing and insulation for MC4 connectors.
The product features a 4:1 shrink ratio, making installation simple and secure. With a tensile strength of 9.8 MPa, it ensures durability and long-lasting performance. It can operate in temperatures from -60°C to 200°C, ensuring stability in extreme environments. The dielectric strength of 23 kV/mm and tear strength of 39 N/mm provide added safety for your connections.
This cold shrink tube is available in black color and ensures excellent sealing for offshore photovoltaic systems.
Properties | Typical Data | Test Method |
Hardness | 40±5 | GB/T 531-2008 |
Tensile strength | ≥7.0MPa | GB/T 528-2009 |
Tensile strength after aging MPa (232℃×7 D) | ≥ 60% of initial value | / |
Elongation at break | ＞800% | GB/T 528-2009 |
Elongation at break after aging % (232℃×7 D) | ≥25% of initial value | / |
Tear strength | ≥25kN/m | GB/T 529-2008 |
Volume resistivity | ≥10 12Ω.m | / |
Flammability | HB | UL 94 |
Requirements for UV/ light aging resistance test | Tensile strength ≥75% of initial value, no surface damage | / |
Durable and reliable insulation: Made of high-quality silicone rubber with 9.8 MPa tensile strength and 23 kV/mm dielectric strength, it can achieve safe connections in low-voltage applications.
Wide temperature range: It can operate in a temperature range of -60°C to 200°C, ensuring stable performance in harsh environments.
Excellent weather resistance: It is resistant to weather, ozone aging and UV rays to protect the connector from environmental damage and extend its service life.
Customizable and versatile: Available in black, it can be customized according to user specifications, and free samples are provided for testing and evaluation.
High-quality materials: It meets international insulation material standards to ensure safe and reliable connections in electronic applications.
UV Resistant: Provides excellent UV protection to ensure long-lasting durability in outdoor environments.
Waterproof: Provides effective waterproofing to protect connectors from moisture and reduce the risk of corrosion.
Salt Spray Resistant: Designed to withstand salt spray, ideal for offshore photovoltaic installations and harsh coastal environments.
Sealed Protection: Provides strong sealing performance to prevent contaminants from affecting the connector.
Ideal for Offshore Photovoltaic MC4 Connectors: Designed for use with MC4 connectors and solar panel junction boxes in offshore environments.
Q1: What is the cold shrink tubing made of?
A1: The cold shrink tubing is made of high-quality silicone rubber, which has excellent insulation and durability.
Q2: What is the temperature range of the cold shrink tubing?
A2: It has an operating temperature range of -60°C to 200°C, suitable for harsh environments.
Q3: Can the cold shrink tubing be used in offshore photovoltaic installations?
A3: Yes, the cold shrink tubing is designed for offshore photovoltaic MC4 connectors and solar panel junction boxes.
Q4: Does the cold shrink tubing provide UV protection?
A4: Yes, it has excellent UV resistance to ensure long-term use in outdoor conditions.
Q5: Is the cold shrink tubing waterproof?
A5: Yes, it provides effective waterproofing to protect the connector from moisture and corrosion.
